A reach truck earns its keep by turning vertical cube into usable storage. That makes the purchase more sensitive to measurements than a general-purpose sit-down forklift. A truck can reach the top beam and still be wrong because the lowered mast misses a doorway, the chassis needs more aisle, or capacity falls below the pallet weight at full extension.
Use the dedicated reach truck inventory and pricing page and verify each configuration against the warehouse drawing and rack data.
Crown ESR-series, Raymond 7000-series, Toyota 9BRU-series and Yale NR/NDR-series reach trucks are common reference points. Single-reach, double-reach, moving-mast and pantograph designs solve different rack layouts. Model names also cover several capacities and heights, so require the dealer to quote the exact chassis, mast and battery—not just the family name.
| Model or category | Good starting application | What to verify |
|---|---|---|
| Crown ESR family | High-density warehouse applications | Exact lift height, capacity, visibility and service package |
| Raymond 7000-series family | Single- and double-deep narrow-aisle work | Reach type, mast, control options and local support |
| Toyota 9BRU family | Distribution and warehouse racking | Battery compartment, aisle requirement and target-height capacity |
| Yale NR / NDR family | Single- and double-reach applications | Rack depth, mast configuration, operator environment and parts support |
A third-party logistics warehouse raises its top beam from 26 to 31 feet and narrows several aisles. Existing reach trucks can touch the height with light pallets, but the heaviest customer loads occupy upper positions during seasonal peaks. The replacement decision cannot be made from maximum fork height alone.
Practical takeaway: The buyer supplies the load schedule and rack elevations, then compares residual capacity at 31 feet, right-angle stack requirements and lowered mast height. The winning truck is not necessarily the one advertising the tallest mast—it is the one that safely handles the actual slotting plan.
Pallet overhang, rack protectors, columns and staging reduce usable space. Ask the dealer to confirm the right-angle stack requirement for the quoted load.
Residual capacity can change with mast, reach mechanism, load center and attachment. Get the configuration-specific data.
Double-deep storage increases density but changes selectivity, visibility, capacity and equipment requirements.
Mast rollers, chains, reach mechanism, steer components, battery condition and fault history can matter more than a low meter reading.
Rack changes, guidance, floor repair, charging, training and WMS slotting can exceed the difference between truck quotes.
A useful quote should identify the exact model and year, rated capacity at the required lift height and load center, mast and lowered height, tires, power source, attachments, operating hours or battery details, warranty, delivery, setup, training assumptions and the final delivered price. If two proposals do not describe the same machine and support scope, the lower number is not automatically the better buy.
Request reach truck prices with the warehouse measurements so dealers can quote a machine that fits the rack, load and aisle together.
Pricing changes with capacity, mast height, battery, charger, reach mechanism, options, freight and support. Current configured quotes are more reliable than a national average.
A reach truck is designed for narrow warehouse aisles and high racking, while a counterbalance truck is more general-purpose and often better suited to docks and mixed surfaces.
Some operations use reach trucks near docks, but under-clearance, floor transitions, dock plates, turning and manufacturer guidance must be evaluated.
It can be when mast, reach mechanism, battery, controls and service history are professionally inspected and the configuration matches the warehouse.
